Wireworld Starlight Ethernet Cable

Better Data Transmission For Streaming Audio.

Reviews

• Stereophile's Audiostream

The Wireworld Starlight Ethernet utilizes an innovative new conductor geometry that supports higher transmission speeds for the most lifelike reproduction of streamed music and video. Patent pending Tite-Shield Technology improves the most critical parameters of digital signal transmission thereby increasing speed and fidelity over standard ethernet cable design.

Cat 8 For Higher Speed Transfer

Unlike Category 7 cables, these innovative cables utilize a new conductor geometry developed by Wireworld to support higher transmission speed for the most accurate & lifelike reproduction of streamed music and video.

Starlight Ethernet is the first production cable thatmeets the proposed requirements for Category 8.This cable is also the first to incorporate Wireworld's patent-pending Tite-Shield Technology, a radical new structure that overcomes limitations of previous network cable designs. With twelve tightly-spaced shields replacing the six unevenly-spaced shields in Category 7 cables, the Tite-Shield design improves the most critical parameters of digital signal transmission. Starlight Ethernet sets new benchmarks for speed and fidelity in high resolution media streaming applications. Category 7 cabling was created to satisfy the demands of 10 Gigabit Ethernet. Even thoughmost media networks now run below that speed, cables that support higher speeds have been found to improve the quality of audio and video streaming. Those improvements are possible because streamed signals suffer from data errors that cannot be repaired by the error correction systems that preserve file transfers. The proposed standard for future networks is Category 8,which extends network speeds to the staggering rate of 40 Gigabits per second.

One of the reasons why CAT7 cables do not meet the proposed CAT8 specifications is that they allow too much crosstalk (mixing) between the four signal channels. To control crosstalk, conventional cables use four twisted pairs of conductors with one foil shield on each pair. An overall two-layer shield reduces outside interference. The problem with twisting is that it makes lengths of the conductors uneven, which causes timing errors called skew. Tite-Shield technology isolates the four channels with a three-layer shield on each conductor pair. Those shields are so effective that twisting is no longer needed and conductor length differences are eliminated.

Starlight's unique flat design provides greater separation between the four conductor pairs to provide lower crosstalk, supporting higher transmission speeds than conventional designs. The cable also utilizes Wireworld's proprietary Composilex insulation to minimize triboelectric noise. The refined transmission properties afforded by these technologies ensure uncompromised performance in the next generation of streaming applications.

Specifications

• Design:Tite-Shield Technology : 100 Ohms
• Signal Conductors:23AWG | 0.26 sq. mm
• Conductor Material:Silver-clad OFC
• Insulation:Composilex 2
• Plug Contacts:24K Gold-plated

Where To Start?

If your streamer is utilizing a wired connection to your home network, start there. If you are running a wireless connection to your streamer, start with the modem to router connection. Ideally, you would want every wired data connection in the path to your streamer to be wired with The Starlight Cat 8 to ensure the highest transfer rate and data integrity.
